2KV Aluminum Solar Cable Manufacturer
PV AL Cable
Key Features of 2kV Aluminum Solar Cable
Application
-
For use in photovoltaic power systems
-
UV/Sunlight-resistant
-
Used at 1000V/2000V
-
Rated 90°C
-
Used on exposed or concealed wiring in wet or dry locations or direct burial
Construction
-
Conductor: 12AWG through 1500MCM Class B compact stranded aluminum alloy (8000 series)
-
Insulation: Flame-retardant cross-linked Polyethylene (XLPE)
Options
-
VW-1
-
Insulation color can be red, black or white *other color available on request
Packaging
-
Customized length trimming
-
Shipped on nonreturnable wooden reels
-
Parallel packaging available
Installation Recommendations
-
Min. Bending Radius during Installation : 10xD (D is diameter of cable)
-
Min. Bending Radius Fix Installed : 8xD (D is diameter of cable)
-
Max. Conductor Operating Temperature : 90°C
Standards
-
UL4703
-
UL44
Why Choose JUNDA as Solar Cable
Supplier
1000V/2000V Photovoltaic (PV) Wire Aluminum – Lightweight, Cost-Effective, and Durable for Solar Applications
Durability and Long-Term
Utilizing a specialized aluminum alloy and a durable, cross-linked polyolefin insulation
Lightweight and Cost-Effective
With its significantly lighter weight compared to copper, our aluminum wire reduces shipping costs
Compliance and Safety
Our product is not only reliable but also fully compliant with local regulations, providing you and
Conductivity for Output
Our aluminum wire is optimized to handle the current requirements of modern PV systems
A Sustainable Choice for the Future
Aluminum is more abundant and requires less energy to produce, making it a more sustainable resource
Related Products
SOLAR BRAN-NEX
Centralized cabling that simplifies system design and reduces installation time
Reliable, scalable solution for utility and commercial solar projects
Our Bran-Nex solutions are designed to optimize solar power distribution by consolidating multiple connections into a single, efficient pathway. This reduces wiring complexity, minimizes installation errors, and ensures safe, reliable performance across large solar installations.
PV HARN-NEX
Smart Harness Connectivity for Next-Generation Solar Systems
Ensures seamless integration, reduces wiring complexity
Our Harn-Nex solutions are designed to deliver smarter, safer, and more efficient connectivity for utility-scale and commercial solar projects. By combining modular design with advanced materials, Harn-Nex minimizes installation time, reduces errors, and optimizes overall system performance—providing future-ready harness solutions for the evolving solar industry.
PVCOMBINER BOX &
PV DISCONNECT BOX
PV Combiner Box:
Streamlines solar string connections, improves system safety, and reduces installation complexity.
PV Disconnect Box:
Provides reliable circuit isolation and protection, ensuring safe maintenance and operation.
Our combiner and disconnect boxes are designed to optimize solar power systems with safe, efficient, and long-lasting performance. The combiner box centralizes connections for better efficiency, while the disconnect box ensures secure isolation and protection. Together, they deliver dependable control and safety for solar projects of all sizes.
Q1: What is 2kV Photovoltaic (PV) Wire Aluminum used for?
2kV PV aluminum wire is designed for solar power systems. It is mainly used to connect photovoltaic panels to inverters, combiner boxes, and other electrical components, ensuring safe and efficient power transmission.
Q2: Why choose aluminum conductor instead of copper?
Aluminum is lighter and more cost-effective while still providing reliable conductivity. This makes it ideal for large-scale solar installations where long cable runs are needed, helping reduce overall project costs.
Q3: What voltage ratings are available?
This PV wire supports 2kV applications, meeting international standards for modern solar projects and ensuring compatibility with today’s high-voltage systems.
Q4: Is it suitable for outdoor installation?
Yes. The cable is UV-resistant, weatherproof, and flame-retardant, ensuring long-term durability in harsh outdoor environments such as extreme temperatures, moisture, and direct sunlight.
FAQ
Q5: Does it meet safety and certification standards?
Yes, it complies with UL, TUV, and IEC standards, ensuring high levels of safety, reliability, and performance for photovoltaic applications.
Q6: Can it be used in both residential and utility-scale projects?
Absolutely. It is suitable for residential rooftop systems, commercial facilities, and large utility-scale solar farms, offering flexibility across different project sizes.
Q7: How does it compare in cost efficiency?
Aluminum PV wire provides significant cost savings compared to copper, especially in large projects, while maintaining excellent conductivity, safety, and performance.
